SETTING THE DMX OPERATING MODE (DMX Mode)
Starting from the main display, press MENU to access the main menu. Now use ⏶ or ⏷ to select
the menu item DMX Mode and confirm with ENTER. Select the desired DMX operating mode
using ⏶ or ⏷ and confirm with ENTER. Tables showing the channel assignment of the different
DMX modes can be found in the DMX CONTROL section of this user manual.
STAND-ALONE MENU
In the stand-alone operating modes (Play Scene and Play Loop), the control signal of the cor-
responding mode can be output to slave units via XLR. If you do not want to output the control
signal, deactivate the output.
A delay can be set for slave units for the time-delayed output of the control signal of the stand-
alone operating modes.
Activate one of the eight available scenes (Scene 1 - 8) or one of the eight available loops (Loop 1
- 8). The settings are made individually for each scene and each loop and are retained even after
the device is restarted.
Starting from the main display, press MENU to access the main menu. Use ⏶ or ⏷ to select
the menu item Stand Alone and confirm with ENTER. Now select the desired sub-menu item,
confirm and then make the settings as required (see table).
16
Relay control signal via DMX OUT and set delay
for slave units:
Off, 0.1s–2.0s
Do not forward control signal
Select and activate the desired scene
