ATTENTION: In order to provide protection from water sprays in accordance with the
IP65 protection class, the special DMX input and output sockets must be used with
special IP65-rated XLR connectors, or they must be closed using the rubber sealing
caps. When connected correctly, or when sealed correctly with the rubber sealing
caps, the POWER IN and POWER OUT sockets are protected from spraying water, as
in accordance with IP65.
7
OLED DISPLAY
The OLED display shows the currently active operating mode (main screen), the menu items,
and the numerical value or operational status of certain menu items. If no input is made within
approximately one minute, the display automatically returns to the main screen. Note on the main
screen in operating modes with external control: in the event that the control signal is interrupted,
the characters in the display begin flashing; once the control signal is present again, the flashing
stops.
8
TOUCH-SENSITIVE CONTROLS
MENU – Press MENU to access the main menu. Press again or repeatedly to return to the main
screen. Pressing MENU without confirming a value or status change by pressing ENTER restores
the previously confirmed value or status.
ENTER – press ENTER to access the menu levels, where you can make value changes and access
the sub-menus with the ENTER button. ENTER is also used to confirm value or status changes.
⏶ and ⏷ – select menu items in the main menu (DMX address, DMX mode, etc.) and in the
sub-menus. Allows you to change the value of a menu option, such as the DMX address (long
press = quick value change).
7
8
13
