Ego Power+ LM2240SP Manuel D'utilisation page 35

This self-propel system is independent from the blade rotation. For example, when you
have completed cutting your lawn, you can use the self-propel to propel the mower
back to your storage location without blade rotation. Or you may choose to operate the
mower as a push mower to maximize battery runtime.
To operate the self-propel system without blades rotation
Slightly rotate the self-propel speed dial forward until a click can be heard, then press
the self-propel trigger(s). There are two self-propel triggers, press either of them to
start the self-propel function.
To turn the self-propel off, release the self-propel trigger.
To operate the self-propel system with the blades rotation
1. Press the power button to illuminate the dashboard.
2. Press the blade speed mode button to select the desired speed.
3. Press the power button.
4. With the power button pressed, pull the bail switch against the handle to start the
mower, then release the power button.
5. Hold the bail switch against the handle with either of your hands. Press either of
the self-propel triggers to start the self-propel function.
6. With one hand holding both the bail switch and the self-propel trigger against the
handle, use the other hand to adjust the self-propel speed-control dial to choose
the desired speed.
NOTICE:
The LCD screen will turn off automatically after 5 minutes of inactivity.
NOTICE:
When you turn off the self-propel, for example, at the end of a row, it may
become temporarily locked if you pull backwards on the mower. Simply push ahead
slightly and then move the mower as required.
NOTICE:
It may, at times, be easier to mow around an object with the self-propel
turned off.
WARNING:
of the bail switch or self-propel system. Use the self-propel system for its intended
purpose only.
56-VOLT LITHIUM-ION CORDLESS 22" LAWN MOWER — LM2240SP/LM2240SP-FC
To reduce the risk of injury, never attempt to override the operation
35
