Manoeuvring
The trailer is manoeuvred according to
the symbols shown on the remote
control. The trailer only moves when
one of the keys is pressed.
If no key is pressed within 20 seconds,
the remote control switches itself off
automatically and must be switched
back on.
Forwards
Right
curve
forwards
Left
curve
backwards
Backwards
Turning to
the right
Turning to
the left
Direction keys
The built-in „soft start" function means that a whistle sounds as a warning
that the caravan or trailer is going to start moving.
Each of the movement keys can be pressed individually or together.
The arrows on the keys indicate the particular movement direction.
} Caution:
Use chocks to prevent the caravan or trailer from rolling away inadvertently.
The parking brake must be applied before the drive rollers are swivelled
away!
Left
curve
forwards
Right
curve
backwards
The drive units are not allowed to be left in contact with the tyres for long
periods, otherwise they could be damaged. Operation with a towing vehicle
whilst the drive units are in contact is prohibited because this could damage
both the caravan or trailer and the towing vehicle.
If the manoeuvring movements do not match the symbols on the remote
control, check the cable connections on the right and left drive units of the
base station and the motor with reference to the connection diagram, and
swap them over if necessary. (Fig. 5)
} Caution:
It is essential to switch off the master switch first and to disconnect the
base station from the electrical power supply.
23
Placing in service and operation
Swivelling the drive rollers away
Following manoeuvring, swivel the drive rollers away from
the tyres by pressing the two arrow keys at the same time:
The MotorDrive switches itself off automatically when it reaches
the limit position.
Switching iMC off
Press the I/O key on the remote control once to
switch off the iMC. The red LED goes out.
Switching off the system
Move the master switch to OFF.
