Content

1. Product description

2. Safety instructions
3. Preparations for installation
4. Installation on BPW chassis
4.1 Classic, Tandem T4 and T2 light
4.2 Vario chassis
5. Installation of the electrical system
6. Placing in service and operation
1. Product description
These instructions use the term „iMC" for the sake of
simplicity, instead of the name „integrated Move Control".
The iMC is one of a range of „i" series products from BPW
Fahrzeugtechnik GmbH & Co. KG. The manoeuvring drive
has been developed and produced with the greatest of care,
based on practical experience.
The iMC is firmly installed on the caravan or trailer. For
manoeuvring purposes, only the left and right drive units
are connected to the tyres. Following manoeuvring, they are
disconnected from the tyres again. The caravan or the trailer
is driven by two 12 volt electric motors. The supplied remote
control allows for safe and convenient manoeuvring.
Symbols on the remote control show you the particular
movement direction.
Content and product description
Anhang
A1. Synchronisation
A2. Reset
A3. Emergency mode
A4. Maintenance
A5. Remarks and tips
A6. FAQs
A7. Warranty conditions
A8. Declaration of conformity
The iMC is available in two versions for BPW chassis with
iMC preparation starting from a particular production date,
and as a clamp-on solution for retrofitting to all other
chassis. The retrofit version can also be mounted on many
non-BPW chassis. If you wish to know whether your caravan
has an iMC preparation, please visit www.bpw-fahrzeug-
technik.de where there is a list showing the various
conversion dates.
The iMC T4 with 4 drive units is available for tandem
caravans (twin axles), and provides a full range of functions.
As a lower priced alternative, there is the iMC T2 with two
drive units. The T2 light version can be uprated to the T4
standard version;BPW Fahrzeugtechnik GmbH & Co. KG
offers an additional package for this.
