ANNEXE
Table 89 : Telegram structure: sWA LFPmedianfilter
Telegram structure: sWA LFPmedianfilter
Telegram Description
part
Command Answer
type
Command Sector function
Table 90 : Example: sWA LFPmedianfilter
<STX>sWA{SPC}LFPmedianfilter<ETX>
CoLa A
02 73 57 41 20 4C 46 50 6D 65 64 69 61 6E 66 69 6C 74 65 72
CoLa B 02 02 02 02 00 00 00 14
12.3.1.4.4.4
Activate the Edge filter to eliminate wrong measurement points at object edges.
Table 91 : Telegram structure: sWN LFPedgefilter
Telegram structure: sWN LFPedgefilter
(User level 'Authorized client' required)
Telegram Description
part
Command Write
type
Command Sector function
Status Activate / deactivate
code edge filter
Enable Edge filter
Table 92 : Example: sWN LFPedgefilter 1
<STX>sWN{SPC}LFPedgefilter{SPC}1<ETX>
<STX>sWN LFPedgefilter 1<ETX>
CoLa A
sWN LFPedgefilter 1
02 73 57 4E 20 4C 46 50 65 64 67 65 66 69 6C 74 65 72 20 31 03
02 02 02 02 00 00 00 13
CoLa B
73 57 4E 20 4C 46 50 65 64 67 65 66 69 6C 74 65 72 20 01
Table 93 : Telegram structure: sWA LFPedgefilter
Telegram structure: sWA LFPedgefilter
Telegram Description
part
Command Answer
type
92 N O T I C E D ' I N S T R U C T I O N | TiM781
Variable Length
String 3
String 15
73 57 41 20 4C 46 50 6D 65 64 69 61 6E 66 69 6C 74 65 72

Activate Edge filter [sWN LFPedgefilter]

Variable Length
String 3
String 13
Bool_1 1
73 57 4E 20 4C 46 50 65 64 67 65 66 69 6C 74 65 72
Variable Length
String 3
Additoinal details
03
Additional details
Inactive:
Active:
Additional details
Values CoLa A Values CoLa B
(ASCII) (Binary)
sWA 73 57 41
LFPmedianfilter 4C 46 50 6D
65 64 69 61 6E
66 69 6C 74
65 72
20 35
Values CoLa A Values CoLa B
(ASCII) (Binary)
sWN 73 57 4E
LFPedgefilter 4C 46 50 65
64 67 65 66
69 6C 74 65
72
0 00
1 01
20 01 32
Values CoLa A Values CoLa B
(ASCII) (Binary)
sWA 73 57 41
