Table 166 : Example: sRN EIgate
<STX>sRN{SPC}EIgate<ETX>
<STX>sRN EIgate<ETX>
CoLa A
sRN EIgate
02 73 52 4E 20 45 49 67 61 74 65 03
02 02 02 02 00 00 00 0A
CoLa B
73 52 4E 20 45 49 67 61 74 65
Table 167 : Telegram structure: sRA Elgate
Telegram Description
part
Command Answer
type
Command Read gateway address
Gateway
Default: 0.0.0.0
address
Table 168 : Example: sRA EIgate 192.168.0.1
<STX>sRA{SPC}EIgate{SPC}C0{SPC}A8{SPC}00{SPC}01<ETX>
CoLa A
02 73 52 41 20 45 49 67 61 74 65
CoLa B 02 02 02 02 00 00 00 0F
12.3.1.4.7.5
Define the subnet mask of the device.
NOTE
• Save permanently to set values. Changes will be active after rebooting the device.
• Settings must correspond with network in which scanner is used. Else device cannot be found any more.
Table 169 : Telegram structure: sWN EImask
(User level 'Authorized client' required)
Telegram Description
part
Command Write
type
Command Set IP mask
8024232/1ONO/2024-09-25 | SICK
Subject to change without notice
73 52 4E 20 45 49 67 61 74 65
Telegram structure: sRA EIgate
Variable Length
String 3
String 6
Uint_8 1
20 C0 A8 00 01
73 52 41 20 45 49 67 61 74 65

Set IP mask [sWN EImask]

Telegram structure: sWN EImask
Variable Length
String 3
String 6
54
Additional details
First part of gateway address
Second part of gateway
address
Third part of gateway address
Fourth part of gateway address 0 ...+255d
03
20 C0 A8 00 01 12
Additional details
ANNEXE
Values CoLa A Values CoLa B
(ASCII) (Binary)
sRA 73 52 41
EIgate 45 49 67 61
74 65
0 ...+255d 00 ... FF
(00...FF)
0 ...+255d 00 ... FF
(00...FF)
0 ...+255d 00 ... FF
(00...FF)
00 ... FF
(00...FF)
Values CoLa A Values CoLa B
(ASCII) (Binary)
sWN 73 57 4E
EImask 45 49 6D 61
73 6B
