ANNEXE
Table 25 : Telegram structure: sRN LMPscancfg
Telegram structure: sRN LMPscancfg
Telegram Description
part
Command Read
type
Command Info of scan frequency
and angular resolution
Table 26 : Example: sRN LMPscancfg
<STX>sRN{SPC}LMPscancfg<ETX>
<STX>sRN LMPscancfg<ETX>
CoLa A
sRN LMPscancfg
02 73 52 4E 20 4C 4D 50 73 63 61 6E 63 66 67 03
02 02 02 02 00 00 00 0E
CoLa B
73 52 4E 20 4C 4D 50 73 63 61 6E 63 66 67
Table 27 : Telegram structure: sRA LMPscancfg
Telegram structure: sRA LMPscancfg
Telegram Description
part
Command Answer
type
Command Info of scan frequency
and angular resolution
Scan fre‐ [1/100 Hz]
quency
Reserved -
Angular [1/10000°]
resolution
Start angle [1/10000°]
Stop angle [1/10000°]
Table 28 : Example: sRA LMPscancfg - 15 Hz scan frequency, 0.33° angular resolution, -45° start angle, +225° stop angle
<STX>sRA{SPC}LMPscancfg{SPC}5DC{SPC}1{SPC}D05{SPC}FFF92230{SPC}225510<ETX>
CoLa A
02 73 52 41 20 4C 4D 50 73 63 61 6E 63 66 67
20 32 32 35 35 31 30
02 02 02 02 00 00 00 21
CoLa B
F9 22 30 00 22 55 10
12.3.1.4.2.2
NOTE
The Factory-Reset (Load factory defaults) deletes the entire parametrization of the device. All parameters, settings
and system applications will be set to default.
70 N O T I C E D ' I N S T R U C T I O N | TiM781
Variable Length
String 3
String 10
73 52 4E 20 4C 4D 50 73 63 61 6E 63 66 67
Variable Length
String 3
String 10
Uint_32 4
Int_16 2
Uint_32 4
Int_32 4
Int_32 4
03
73 52 41 20 4C 4D 50 73 63 61 6E 63 66 67
EF

Load factory defaults [sMN mSCloadfacdef]

Additional details
63
Additional details
15 Hz:
Always:
0.333°:
-45°
+225°
20 35 44 43 20 31 20 44 30 35
20 00 00 05 DC 00 01 00 00 0D 05 FF
Values CoLa A Values CoLa B
(ASCII) (Binary)
sRN 73 52 4E
LMPscancfg 4C 4D 50 73
63 61 6E 63 66
67
Values CoLa A Values CoLa B
(ASCII) (Binary)
sRA 73 52 41
LMPscancfg 4C 4D 50 73
63 61 6E 63 66
67
5DCh 00 00 05 DC
7D0h
1 00 01
D05h 00 00 0D 05
FFF92230h FF F9 22 30
225510h 00 22 55 10
20 46 46 46 39 32 32 33 30
