Set Ethernet Gateway [Swn Elgate] - Sick Tim781 Notice D'instruction

Table 158 : Example: sRN EIIpAddr
<STX>sRN{SPC}EIIpAddr<ETX>
<STX>sRN EIIpAddr<ETX>
CoLa A
sRN EIIpAddr
02 73 52 4E 20 45 49 49 70 41 64 64 72 03
02 02 02 02 00 00 00 0C
CoLa B
73 52 4E 20 45 49 49 70 41 64 64 72
Table 159 : Telegram structure: sRA EIIpAddr
Telegram Description
part
Command Answer
type
Command Read IP address
IP address Default: 192.168.0.1
Table 160 : Example: sRA EIIpAddr 192.168.0.2
<STX>sRA{SPC}EIIpAddr{SPC}C0{SPC}A8{SPC}00{SPC}02<ETX>
CoLa A
02 73 57 41 20 45 49 49 70 41 64 64 72
CoLa B 02 02 02 02 00 00 00 11
12.3.1.4.7.3
Change Ethernet gateway IP address (TCP/IP)
NOTE
• Save permanently to set values. Changes will be active after rebooting the device.
• Settings must correspond with network in which scanner is used. Else device cannot be found any more.
Table 161 : Telegram structure: sWN Elgate
(User level 'Authorized client' required)
Telegram Description
part
Command Write
type
Command Set gateway adress
8024232/1ONO/2024-09-25 | SICK
Subject to change without notice
73 52 4E 20 45 49 49 70 41 64 64 72
Telegram structure: sRA EIIpAddr
Variable Length
String 3
String 8
Uint_8 1
20 C0
73 52 41 20 45 49 49 70 41 64 64 72

Set Ethernet gateway [sWN Elgate]

Telegram structure: sWN EIgate
Variable Length
String 3
String 6
49
Additional details
First part of IP address
Second part of IP address
Third part of IP address
Fourth part of IP address
20 A8 20 00 20 02 03
20 C0 A8 00 02
Additional details
ANNEXE
Values CoLa A Values CoLa B
(ASCII) (Binary)
sRA 73 52 41
EIIpAddr 45 49 49 50
41 64 64 72
0 ...+255d (00 00 ... FF
... FF)
0 ...+255d (00 00 ... FF
... FF)
0 ...+255d (00 00 ... FF
... FF)
0 ...+255d (00 00 ... FF
... FF)
0C
Values CoLa A Values CoLa B
(ASCII) (Binary)
sWN 73 57 4E
EIgate 45 49 67 61
74 65
