Table 29 : Telegram structure: sMN mSCloadfacdef
Telegram structure: sMN mSCloadfacdef
(User level 'Authorized client' required)
Telegram Description
part
Command Method
type
Command Load factory defaults
Table 30 : Example: sMN mSCloadfacdef
<STX>sMN{SPC}mSCloadfacdef<ETX>
<STX>sMN mSCloadfacdef<ETX>
CoLa A
sMN mSCloadfacdef
02 73 4D 4E 20 6D 53 43 6C 6F 61 64 66 61 63 64 65 66 03
02 02 02 02 00 00 00 11
CoLa B
73 4D 4E 20 6D 53 43 6C 6F 61 64 66 61 63 64 65 66
Table 31 : Telegram structure: sAN mSCloadfacdef
Telegram structure: sAN mSCloadfacdef
Telegram Description
part
Command Answer
type
Command Load factory defaults
Table 32 : Example: sAN mSCloadfacdef
<STX>sAN{SPC}mSCloadfacdef<ETX>
CoLa A
02 73 4D 4E 20 6D 53 43 6C 6F 61 64 66 61 63 64 65 66
CoLa B 02 02 02 02 00 00 00 12
12.3.1.4.2.3
NOTE
The Application-Reset (Load application defaults) deletes only the user parametrization of the Fields, Evaluation
cases (EVC) and parameters under the header "Application". Other parameters like Interface settings, Echo Filter,
etc. remain unaffected.
Table 33 : Telegram structure: sMN mSCloadappdef
Telegram structure: sMN mSCloadappdef
(User level 'Authorized client' required)
Telegram Description
part
Command Method
type
8024232/1ONO/2024-09-25 | SICK
Subject to change without notice
Variable Length
String 3
String 13
73 4D 4E 20 6D 53 43 6C 6F 61 64 66 61 63 64 65 66
Variable Length
String 3
String 13
73 41 4E 20 6D 53 43 6C 6F 61 64 66 61 63 64 65 66

Load application defaults [sMN mSCloadappdef]

Variable Length
String 3
Additional details Values CoLa A
sMN
mSCloadfacdef
28
Additional details Values CoLa A
sAN
mSCloadfacdef
03
20 04
Additional details Values CoLa A
sMN
N O T I C E D ' I N S T R U C T I O N | TiM781
12
ANNEXE
Values CoLa B
(ASCII) (Binary)
73 4D 4E
6D 53 43 6C
6F 61 64 66 61
63 64 65 66
Values CoLa B
(ASCII) (Binary)
73 41 4E
6D 53 43 6C
6F 61 64 66 61
63 64 65 66
Values CoLa B
(ASCII) (Binary)
73 4D 4E
