9.2 Tyre pressure

The maximum tyre pressure depends on tyre width and inner rim width. You can use the tyre and rim manufacturers'
specifications when adjusting the tyre pressure. Do not exceed the maximum tyre pressure!
On many bikes, it makes sense to choose a tyre pressure that is lower than the maximum pressure for a more
comfortable ride. The minimum tyre pressure is also marked on the tyre sidewall and you should not fall below this value
either.

9.3 Further information

For further information on spare parts, tightening torques and exploded-view drawings for your frame, please refer to the
frame details on rosebikes.com/services/service/manuals.
Want to adjust, replace or service components yourself and according to your own requirements? If you are certain that
you have sufficient knowledge and skills for it, you will find all necessary information about these tasks on the respective
manufacturer's website. Please bear in mind that you take responsibility for all jobs carried out by yourself.
Here are some links to the websites of popular manufacturers:
Bosch: https://www.bosch-ebike.com/
Shimano: https://si.shimano.com/
Rock Shox / SRAM: https://www.sram.com/en/service
DT Swiss: https://www.dtswiss.com/en/support
Fox: https://www.ridefox.com/fox17/help.php?m=bike&t=tuningtips

9.4 Torques

General tightening torques
All nuts and bolts must be tightened with an appropriate torque wrench. Proper use prevents overtightening and breaking
of the bolts.
Components
Seatpost clamp
Stem
Brake calliper mounting front wheel
Front axle
Cassette lockring
Rear derailleur bolt
Brake rotor bolts
Centre lock brake disc lockring
Crank bolt
Bottom bracket
Pedals
Operating elements at the handlebar
Threaded eyelets on the frame
*The torque value must not be exceeded. As a rule, a lower torque is sufficient for a secure hold. Especially when using
assembly paste, the necessary torque is often much lower, because the solid particles in the lubricant significantly
increase the friction.
Manufacturer / Torque
Model
ROSE max. 4 Nm
Steerer clamp: max. 8 Nm
Level Nine Race
Handlebar clamp: max. 8 Nm
Steerer clamp: 5 - 6 Nm
Handlebar clamp:
Reverse Black One
• upper clamp bolts 6 Nm
• lower clamp bolts 1 Nm
all 6 Nm
all See manufacturer's instructions
all 40 Nm
all 10 Nm
6.2 Nm
all
all 40 Nm
all See torque value indicated
BSA 40 Nm
35 Nm
all
See torque value indicated*
all Pay attention to additional instructions from
the handlebar manufacturer!
- 2 Nm*
