Rose ROOT MILLER + Manuel D'instructions page 56

Removing the battery pack
1. Insert the key into the lock and turn it around.
→ The battery pack is released and secured by a safety restraint.
2. Press down the safety restraint to completely unlock the battery.
3. Remove the battery pack from the frame.
Charging the battery when removed from the e-bike
1. Plug the charging cable (3) into the port on the battery pack
(2).
2. Plug the mains cable (5) into the socket on the charger (4).
3. Connect the mains cable to a 230 V mains socket.
→ Once the mains cable is connected, the battery is charged
automatically.
→ During the charging process, the charge indicator LEDs
(1) light up.
Each continuously lit LED is equivalent to approximately
20% capacity. The flashing LED indicates the charging of
the next 20%.
→ Once the e-bike battery is fully charged, the LEDs turn off
immediately and the battery is switched off. This means
that charging is completed.
4. Disconnect the charging cable (3) from the socket (2), if need
be, and unplug the mains cable (5).
5. Fit the battery pack to the frame of your bicycle if need be (see "5.7 Inserting the battery and attaching the cover").
56
1
2
5
4
3
