TECHNICAL DATA

• MEASUREMENTS / WEIGHT
Boiler height:
Boiler depth:
Boiler width:
Weight:
Gas:
Output 1:
- Consumption:
Output 2:
- Consumption:
Pressure:
• VOLUME/PRESSURE/TEMP
Liquid volume glycol/water:
Liquid volume hot water:
Max pressure radiator water:
Max pressure warm water:
System temperature (max):
120 V ~
Output element:
12 V DC
Current consumption:
Fuse:
1.

OPERATING INSTRUCTIONS HEATING

These instructions are approved for The Alde Compact 3020 heating system installed in Recreational Vehicles (RVs)
as detailed in Standard ANSI Z21.13-2014, CSA 4.9-2014.
1.1

Checking the heating system before use

• Check the fluid level in the expansion tank as in section 1.11 (Glycol heating fluid).
• Check that the flue is kept free of snow and ice, as induction air enters the boiler via the flue when operated on
LP gas. Also check that other objects are not obstructing or disrupting flue gases and supply air at the flue. When
checking the flue, make sure that the main gas valve to the LP gas system is closed.
• Check the air circulation as in section 1.6 (The principle of convection).
WARNING
VARNING
Do not drink any alcohol or take any drugs before or
during the operation of the heating system and follow
AVERTISSEMENT
the safety instructions carefully.
WARNUNG
ADVARSEL

The first time the heating system is started

1.2
VAROITUS
• Hot water boiler: Always flush the hot water boiler before using for the first time or if it has not been used for a long
ADVERTENCIA
period. See section 1.7 Using the heating system (DOMESTIC HOT WATER)
• Carry out a check as in section 1.1 (Checking the heating system before use).
AVVERTENZA
• Start the heating as described in section 2.1 (STARTING THE HEATING SYSTEM).
WAARSCHUWING
• Select language, this appears when the panel is started for the first time, see section 2.9 point 22.
• Check that the right accessories have a checkmark next to them in the list of installed functions, see section 2.12.
• Set the clock, see section 2.9 point 4.
• Set the desired operating mode (gas and/or electric) and the desired interior temperature, see sections 2.4, 2.6
and 2.7. The LP Gas heating and electric heating can be operated simultaneously, but this should be avoided in
newly filled systems.
12.25 in / 310 mm
13.5 in / 340 mm
20 in / 510 mm
31 lb / 14 kg (without fluid)
Propane
11K Btu - 3,3 kW
0.54 lb/h - 245 g/h
18.7K Btu - 5,5 kW
0.9 lb/h - 405 g/h
27 - 35 mbar
0.92 gal / 3,5L
2.2 gal / 8,4L
0,05 MPa (0,5 bar)
0,3 MPa (3,0 bar)
176 °F / 80 °C.
2 x 950 W
1.9 amp (max)
3.15 amp
CAUTION
OBSERVERA
When this heating system is in operation;
Always be aware of hot surfaces. ATTENTION
VOORZICHTIG
