HEATING WITH ELECTRICITY

Proceed as follows to activate heating with electricity. Set the power level according to the fuse for incoming electricity
to the vehicle. Or set the power to max (2kW) and use a load monitor*
If both electricity and gas are selected, a priority can be set, see 2.9, section 3.
72.0°
F
2 kW
2.7

HEATING WITH GAS

Proceed as follows to activate heating with gas.
If both electricity and gas are selected, a priority can be set, see 2.9, section 3.
72.0°
F
2 kW
Functions marked with a (*) are accessories, which are not installed on all vehicles, refer to the vehicle manufacturer's
18
instructions.
2. Normal operation. If hot water is required, press the "+" button (the
symbol will then be half-shaded). If the 2.9, section 12 (Floor heat-
ing*) function has been set to Cont., this option cannot be selected.
When only hot water is required, e.g., during the summer or when no
heating is needed, no settings need to be made; the heating system
handles this function automatically.
WARNING
VARNING
Since the hot water and antifreeze in the heating sys-
tem are heated simultaneously, the hot water can be
AVERTISSEMENT
very hot when a high level of heating is required.
WARNUNG
ADVARSEL
3. Extra hot water. If you need more hot water, the water temperature
VAROITUS
can be temporarily increased to about 149 °F/65 °C. Press the "+"
ADVERTENCIA
button so that the symbol is fully shaded (black). The heating system
returns to normal operation after 30 minutes. Once you have selected
AVVERTENZA
extra hot water, the circulation pump stops.
If the 2.9, section 12 (Floor heating*) function is set at Cont., the
WAARSCHUWING
continuous pump operation function is turned off for 30 minutes, but
returns thereafter to continuous pump operation.
If an Alde Flow*
(part no. 3020 163)
hot water mode, up to 1 gallon (3.78 liters)/minute of hot water can
be supplied. The hot water function can then remain in operation for
longer than 30 minutes.
1. Start and stop between the
various power steps (Off, step
1, step 2) with the + button
or – button. The set value is
displayed on the screen.
When activated, the plus sym-
bol changes color to green.
1. Start gas operation by pressing
the flame symbol. Gas opera-
tion is activated and the flame
symbol changes color to green.
SCALDING INJURY
is installed and the panel is in extra
(part no 3010 642)
2. The settings are ready and the
heating is working at the set
temperature.
3. To switch off electrical opera-
tion, step with the – button to
Off.
2. The settings are now complete
and the heating system will op-
erate at the set temperature.
3. To switch off gas operation,
press the flame symbol, which
will change color to blue.
