3. Components and connectors

Description
1 Socket for Probe: probe 226 Hz/1000 Hz/OAE Probe + air pressure tube
2 Socket for Contralateral stimulation transducer connection
3 7" TFT Resistive touch screen display
4 External body
5 Main switch
6 Led: shows that battery is charging
7 Socket for external medical power supply
8 Not in use
9 USB Host port for connection of pen drive (for software) or external keyboard. Wi-Fi
dongle and otoscope
R16M User's Manual – Page 87
