Angle or rotation of
the door handle: 27°
Single turn locking
EN
38

Function and operation

General

The mortice lock has holes drilled in it for the end-to-end fastening of oval and
round rosettes and long escutcheons.
When unlocked, it is opened using a door handle with end-to-end spindle. The
angle of rotation of the door handle is 27°.
The lock is completely locked by turning the key (single turn locking). When
locked, the lock can no longer be opened using the handle.
Function and operation
