ENGLISH

5.2 Connection and electrical data

Speed:
Nominal widths DN:
Pipe joints
Permissible media temperature min/max
Ambient temperature min/max
Permissible humidity
Max. permissible working pressure
Insulation class
Protection
Electromagnetic Compatibility (EMC)
emitted interference according to
noise immunity according to
Sound pressure level
Flow media
Electrical connections
Power output
Motor temperature sensor
Speed control
Storage temperature
x Standard model
X Special model or optional equipment (additional charge)
When ordering spare parts, please specify all information on the
pump/motor rating plate.
Electrical data (power and current consumption), dimensions and
weights are given in the catalogue. The pumps are intended for use
in TN or TT systems. Their use in IT systems (unearthed systems)
may be authorised after consultation with the manufacturer.
Flow media:
If water/glycol mixtures with a ratio of 10% or more glycol (or flow
media with a viscosity other than that of pure water) are used, the
increased power consumption of the pump is to be taken into
account. Only brand products with anti-corrosion inhibitors should
be used. The manufacturer's instructions must be strictly adhered
to.
The flow medium must be free of sediment.
x
If another medium is to be used, it must be cleared by Wilo.
x

5.3 Scope of supply

Pump IP-E / DP-E
x

Installation and Operating Instructions

x

5.4 Accessories

Accessories must be ordered separately.
IP-E and DP-E: 3 consoles with mounting material for installation
x
on a foundation
DP-E: blind flange for repair purposes
x
IF module PLR for connection to PLR/interface converter. With a
x
DP-E, only one IF module is required in the master for this purpo-
se.
IR monitor
x
IF module LON for connection to the LONWORKS network. With a
x
DP-E, only one IF module is required in the master for this purpo-
se.
32
2900 rpm depending on power output
32,40; 50; 65; 80
Flange PN 10 drilled to EN 1092-2
- 10°C ... + 120°C
- 10°C to 40°C (50°C after separate release by the manufacturer)
0...95 %
10 bar
F
IP 55
EN 61800-3
EN 61800-3
< 71 dB(A)
Heating water according to VDI 2035
Cooling and cold water
Water/glycol mixture with up to 40% vol. glycol
Heat-conducting oil
Other media upon request
3 ~ 400 V ± 10%, 50 Hz
3 ~ 380 V + 15%, - 5 %; 60 Hz
short-circuit-proof according to EN 61800-5-1
PTC
integrated frequency converter
-20°C to +70°C
6

Description of product and accessories

6.1 Pump and motor

All the pumps described here are single-stage low-pressure circu-
lation pumps in a compact design with coupled motor. The pumps
can be assembled directly as inline pumps in a well-fastened pipe-
line or placed on a foundation base.
IP-E: The pump housing is of an INLINE design, i.e. the suction
x
and discharge flanges are on a common centre line. All pump
housings are provided with pump feet. It is recommended that
the pump be installed on a foundation base.
DP-E: Two pumps are arranged in the same housing (double
x
pump). The pump housing is of an INLINE design. All pump hou-
sings are provided with pump feet. It is recommended that the
pump be installed on a foundation base.
An electronic module attached to the motor housing regulates the
speed of the pump to a nominal value within a permissible range of
values. Depending on the control system involved, the differential
pressure is subject to different criteria. Regardless of the control
system involved, the pump continually adapts itself to the varying
power requirements of the units, especially when being used in
conjunction with thermostatic valves or mixers.
The main benefits of electronic control are as follows:
it does not require overflow valves,
x
it saves energy,
x
it reduces noise caused by the flow.
x
it allows the pump to adapt to varying operating conditions
x
x
x
x
x
X
x
x
x
x
