Commissioning
Code table (excerpt)
Code
No. Name
[C0002] [C0002]* Parameter set Parameter set
U U U U S S S S E E E E r r r r transfer/reset f
[C0002]* Parameter set
U U U U S S S S E E E E r r r r
transfer/reset
(continued)
C0003* ¿ Non-volatile
parameter saving parameter saving
32
Possible settings
Lenze Selection
-0- -0- Function executed
Parameter sets (PARx) of the controller
-1- Lenze setting
... ...
-4-
Lenze setting
-10- Keypad
-11- Keypad
... ...
-14-
Keypad
-20- PAR1 ... PAR4
Parameter sets (FPARx) of the function
module INTERBUS, PROFIBUS-DP or
LECOM-B on FIF
-31- Lenze setting
... ...
-34-
Lenze setting
-40- Keypad
-41- Keypad
... ...
-44-
Keypad
-50- FPAR1 ... FPAR4
Parameter sets controller (PARx) +
function module (FPARx) Application-I/O,
INTERBUS, PROFIBUS-DP or LECOM-B on
FIF
-61- Lenze setting
... ...
-64-
Lenze setting
-70- Keypad
FPAR4
-71- Keypad
... ...
-74-
Keypad
-80- PAR1 ... PAR4 + FPAR1 ... FPAR4
Keypad
-1- -0- Do not save parameter in EEPROM
-1- Always save parameter in EEPROM
EDK82EV3 DE/EN/FR 2.0
ð PAR1
ð PAR4
ð PAR1 ... PAR4
ð PAR1
ð PAR4
ð Keypad
ð FPAR1
ð FPAR4
ð FPAR1 ... FPAR4
ð FPAR1
ð FPAR4
ð Keypad
ð PAR1 + FPAR1
ð PAR4 + FPAR4
ð PAR1 ... PAR4 + FPAR1 ...
ð PAR1 + FPAR1
ð PAR4 + FPAR4
IMPORTANT
Always required for
operation
without function
l
module on FIF
with Standard-I/O on
l
FIF
with system bus
l
(CAN) on FIF
Overwrite selected
parameter set with
default setting
Overwrite all parameter
sets with the keypad
data
Overwrite the parameter
set selected with the
keypad data.
Copy all parameter sets
to the keypad
Overwrite selected
parameter set with Lenze
setting
Overwrite all parameter
sets with the keypad
data
Overwrite the parameter
set selected with the
keypad data.
Copy all parameter sets
to the keypad
Overwrite selected
parameter set with
default setting
Overwrite all parameter
sets with the keypad
data
Overwrite the parameter
set selected with the
keypad data.
ð Copy all parameter sets
to the keypad
Data loss after mains
disconnection
Active after every
l
main connection
Cyclic parameter
l
changes via bus
module are not
allowed.
L
