Switch-on sequence
13. Enter the motor data
E. Rated motor speed (C0087)
Lenze setting: 1390 rpm
F. Rated motor current (C0088)
Lenze setting: Depending on the
controller
G. Rated motor frequency (C0089)
Lenze setting: 50 Hz
H. Rated motor voltage (C0090)
Lenze setting: Depending on the
controller
Motor-cos ϕ (C0091)
I.
Lenze setting: Depending on the
controller
14. Motor parameter identification
(C0148)
A. Ensure that the controller is inhibited
(terminal X3/28 = LOW)
B. Set C0148 = 1
v
press
C. Enable the controller
(terminal X3/28 = HIGH)
D. If the segment becomes active after
approx. 30 s,
must be activated.
(terminal X3/28 = LOW)
15. If necessary, adjust more
parameters
After parameter setting:
16. Setpoint selection
17. Enable the controller.
18. The drive should now be running at
e.g. 30 Hz
L
w x
c
controller inhibit
EDK82EV3 DE/EN/FR 2.0
Commissioning
z
@ ?
Πj g f k i h PS
y R m n o
q r
Hi
Lo
The motor makes a high-pitched
tone. The motor does not rotate!
Calculated and stored:
V/f rated frequency (C0015)
l
Slip compensation (C0021)
l
Motor stator inductance (C0092)
l
Measured and stored:
Motor stator resistance (C0084)
l
= Total resistance of motor cable
and motor
E. g. JOG frequencies (C0037,
C0038, C0039), deceleration time
for quick stop (QSP) (C0105) or
motor temperature monitoring
(C0119)
E.g. via potentiometer at terminals
7, 8, 9
@ ? > A =
Πj g f k i h PS
R m n o
F
q r
Hi
Lo
Vector control
Note
See motor nameplate
Enter the value for the
motor connection type
(star/delta) selected!
Enter the value for the
motor connection type
(star/delta) selected!
> A =
F
Hz
Identification starts, the
c
segment
Identification is completed.
Terminal X3/28 = HIGH
If the drive does not start,
u
press
Hz
7
is off.
.
