Connection/disconnection of wiring in push-in type terminals

7. Connection/disconnection of wiring in push-in type
terminals
The connection of the storage system, the consumption grid and the auxiliary grid/genset is performed using
push-in type terminals.
This section describes the connection and disconnection process of the wiring in these terminals, as well as the
tool to use.
Required tool
To operate on these terminals, use a flat-head screwdriver with the maximum dimensions specified in the following
figure.
