Commissioning
Delete entries
➜
To delete an entry from the list, touch the associated
Delete button. During the deletion, the assigned
Delete button is highlighted in yellow:
Save entries on USB stick
Recorded entries can be saved on an USB-stick. To do
this, connect a VFAT-formatted USB stick to the USB port
of the display and open the data list as described.
As soon as a USB stick is connected, a
(diskette symbol) is assigned to each list entry.
➜
To save an entry from the list, touch the associated
Save
button. During the saving, the assigned
button has a yellow background:
PRACTICAL TIP
Large amounts of data are generated during the long-term recording of
process data (several days).
It is therefore recommended to save the current data recording memory
on a USB stick and to remove the existing entries from the internal
memory before starting the process.
Connectivity
All necessary network parameters and settings for time synchronization can be defined in the
[Hei-CONTROL Pro] menu:
All associated parameters can be defined manually in
the [static IP configuration] mode (checkbox deselected).
Select the checkbox to obtain the IP address of the device
automatically.
Select the [NTP server] checkbox to synchronize the
system time of the device with a time server. This function
requires a valid IP configuration! Place the cursor in the
corresponding input field and use the on-screen keyboard
to enter the required server address.
Select the [RS 232 Distimatic Pro] checkbox if the
device is to be connected directly to an automatic
Hei-VOLUME Distimatic Pro module and will be controlled
by it.
Deselect the [RS 232 Distimatic Pro] checkbox if the
device is to be activated via the RS 232 interface of the
control panel and thus via a compatible external control
(for further information, see sections „Remote mode" on
page 108 and „RS 232 interface commands" on page
113).
Save
button
Save
94
