13. Cleaning and maintenance
Attention!
Disconnect the mains plug before carrying out any
maintenance work.
Cleaning
• Keep protective devices, air vents and the motor
housing as free of dust and dirt as possible. Rub
the device clean with a clean cloth or blow it off with
compressed air at low pressure. We recommend
that you clean the device directly after every use.
• Clean the device at regular intervals using a damp
cloth and a little soft soap. Do not use any cleaning
products or solvents; they could attack the plastic
parts of the device. Make sure that no water can
penetrate the device interior. Water entering a pow-
er tool will increase the risk of electric shock.
General maintenance tasks
Wipe swarf and dust off the machine from time to time
with a cloth.
Do not oil the motor.
Do not use corrosive cleaning agents for cleaning the
plastic.
Maintenance
Brush inspection (Fig. 22)
If the machine is new, check the carbon brushes after
the first 50 operating hours or if a new brush has been
mounted. After the initial check, check every 10 oper-
ating hours.
If the carbon is worn down to a length of 6 mm, or the
spring or the shunt wire is burnt or damaged, both
brushes must be replaced. If the brushes are found to
be usable after removal, they can be reinstalled.
1.
To service the carbon brushes, open both locks
(as shown in figure 22) counterclockwise.
2.
Then remove the carbon brushes.
3.
Re-insert the carbon brushes in reverse order.
34 | GB
www.scheppach.com
Replacing the saw band (Fig. 7-11)
Attention!
Disconnect the mains plug before carrying out any
maintenance work.
1.
Rotate the tightening lever for the saw band (13)
in a clockwise direction up to the stop, in order
to relieve the saw band tension (see Figure 7).
2.
Turn the metal band saw over and place it down
on a workbench or table like this.
3.
Loosen the Phillips screws (a) and remove the
saw band guard (9) (left/right) by sliding to the
left or right.
4.
Start to remove the saw band at the top part
of the saw band guard (14) and continue right
around the drive unit of the saw band (16). When
removing the saw band, the tension may be re-
lieved and the saw band may jump off. SAW
BANDS ARE SHARP. WEAR PROTECTIVE
GLOVES WHEN HANDLING THEM.
5.
Check the guide rollers (18) and remove all
coarse chips that may be in here. Jammed chips
may prevent the guide rollers (18) from turning
and lead to flat spots.
6.
Rubber belts (17) are located on the pulleys (13).
The rubber belts should be checked for loose-
ness or damage when changing the saw band.
Wipe chips off the rubber belts (17).
7.
Position the saw band (11) such that the teeth
are on the base and are angled in the direction
of the workpiece stop (10), as shown in Figure 9.
8.
Slide the saw band (11) into the guide rollers (18),
as shown in Figure 10.
9.
Hold the saw band (11) in the guide rollers (18)
and place it around both drive units (16).
10.
Tension the saw band (11) using the tightening
lever for the saw band (13).
11.
Push the saw band guard (left/right) (9) back on-
to the metal band saw and screw it tight again.
12.
Attention! Do not operate the metal band saw
without the saw band guard!
13.
Switch the metal band saw on and off a few
times, to ensure that the saw band is sitting cor-
rectly.
m CAUTION:
Maintain physical distance from the saw band
area during this test.
Service information
With this product, it is necessary to note that the fol-
lowing parts are subject to natural or usage-related
wear, or that the following parts are required as con-
sumables.
Wearing parts*: Carbon brushes, saw band
* may not be included in the scope of supply!
Spare parts and accessories can be obtained from our
service centre. To do this, scan the QR code on the
cover page.
14. Storage
Store the device and its accessories in a dark, dry and
frost-free place that is inaccessible to children. The op-
timum storage temperature lies between 5 and 30 ˚C.
Store the power tool in its original packaging.
Cover the electric tool to protect it from dust or mois-
ture.
Store the operating manual with the power tool.
15. Transport
Transport the metal band saw by holding it with both
hands by the handles (1) and (8).
Carry the machine on the saw table (21) with the metal
band saw mounted to the saw table.
16. Disposal and recycling
Notes for packaging
The packaging materials are recy-
clable. Please dispose of packag-
ing in an environmentally friendly
manner.
Notes on the electrical and electronic equipment
act [ElektroG]
Waste electrical and electronic equipment
does not belong in household waste, but
must be collected and disposed of sepa-
rately!
• Used batteries or rechargeable batteries that are not
installed permanently in the old appliance must be
removed non-destructively before disposal. Their
disposal is regulated by the battery law.
www.scheppach.com
• Owners or users of electrical and electronic devices
are legally obliged to return them after use.
• The end user is responsible for deleting their per-
sonal data from the old device being disposed of!
• The symbol of the crossed-out dustbin means that
waste electrical and electronic equipment must not
be disposed of with household waste.
• Waste electrical and electronic equipment can be
handed in free of charge at the following places:
- Public disposal or collection points (e.g. municipal
works yards)
- Points of sale of electrical appliances (stationary
and online), provided that dealers are obliged to
take them back or offer to do so voluntarily.
- Up to three waste electrical devices per type of
device, with an edge length of no more than 25
centimetres, can be returned free of charge to
the manufacturer without prior purchase of a new
device from the manufacturer or taken to another
authorised collection point in your vicinity.
- Further supplementary take-back conditions of
the manufacturers and distributors can be ob-
tained from the respective customer service.
• If the manufacturer delivers a new electrical appli-
ance to a private household, the manufacturer can
arrange for the free collection of the old electrical
appliance upon request from the end user. Please
contact the manufacturer's customer service for
this.
• These statements only apply to devices installed
and sold in the countries of the European Union
and which are subject to the European Directive
2012/19/EU. In countries outside the European Un-
ion, different regulations may apply to the disposal of
waste electrical and electronic equipment.
GB | 35
