- Check that the master switch is in the "0" position (off).
- Connect the centrifuge making sure that the mains
supply is as specified on the characteristics label in sec-
tion 1.2 or 2.2.
- Press the master switch, press the ON/OFF icon when
the touchscreen is enabled, and press the icon to open
the door. Inside there should be 4 protected tube holders,
with their bioseals and lids corresponding. Numbered co-
rrelatively.
- Once they have been unpacked and placed in their po-
sition in the rotor, close the door.
The centrifuge is now installed.
If any material is missing, it is not as specified or is defecti-
ve, contact your distributor.
SECTION II: DESCRIPTION
This section describes the technical and functional cha-
racteristics.
FUNCTIONAL CHARACTERISTICS
The centrifuge is a robust product. Its exterior frame and
its centrifugation chamber are made of enamelled steel.
The inner parts are zinc-coated or are made of aluminium.
The fasteners are stainless steel. This makes them highly
resistant to corrosion and facilitates their cleaning.
The anodised rotor and tube holder offer a high resistan-
ce to corrosion and scratching, in addition to facilitating
its cleaning. Their design makes it possible to achieve sui-
table speeds, maintaining its safety.
Using the centrifuge correctly, none of the materials that
comprise the centrifuge will reach extremes of fatigue.
Equipped with a display and a touchpad to control the fo-
llowing parameters:
Page 4
ENDORET
- switching on and off
- opening the cover
- start and emergency stop
- impossible start up the rotor with the cover open or not
properly closed
- impossible open the cover if the rotor not is fully
stopped
- automatic stop of the rotor in the event of excessive im
balance of the load, with acoustic warning
- automatic stop of the rotor in the event of emergency
opening, with acoustic warning
- energy saving system in which after 5 minutes without
use, the screen turns off
- warning of unbalanced rotor
- warning of motor fault
The display, the touchpad and the acoustic warning indi-
cate the operational process it is in at all times.
The rotation speed is limited to 1902 rpm.
TECHNICAL CHARACTERISTICS*
Benchtop centrifuge:
- Power supply (**)
- Maximum frequency
- Max. power consumption
- Current
- Fuse (type T)
- Maximum capacity
- Max. centrifugal force
- Max. time
- Class (according to CISPR 11) (***)
- Max. noise level
- Program memories
- Temperature margin
- Relative humidity
- Dimensions: (W/D/H)
- Weight
- Warranty
Transport and storage conditions:
- Humidity
- Temperature
* These technical characteristics are for:
- Ambient temperatures between 2ºC and 40ºC.
- Grid margin ± 10%.
- Relative humidity
- For installation category II b.
- Pollution class I
®
MODEL SYSTEM V
100 - 240 V
50/60 Hz
100 – 250 W
1.5 A
2 x T 2A L (5 x 20 mm
16x9 ml
1902 rpm
8 min.
< 85 dB
1 factory-set program
2ºC - 40ºC
<75%
360x455x239 mm
16.62 kg.
24 (twenty-four months)
< 90%
-18ºC to 40ºC
< 75%
