CONVERTING FROM
BRUSHCUTTER (SAW BLADE)
Removing the cutting attachment guard
See fi gure 8.
1. Stop the engine.
2. Remove the cutting attachment guard from the
mounting bracket.
Removing the ReelEasy™ grass trimmer head
See fi gure 8.
1. Open the ReelEasy™ Grass Trimmer Head by
depressing the latches on each side. The contents of
the bump head are spring loaded, so keep your other
hand over the string head cover while depressing the
latches.
2. Remove the string head cover, bump knob, and line
spool.
3. Place the Allen wrench through the hole in the upper
fl ange washer and the hole in the gear head. Using a
wrench, turn the drive connector clockwise to remove.
4. Remove the drive connector and string head housing
from the gear head.
NOTE: Store the disassembled parts together for later
use.
Installing the saw blade guard
See fi gure 8.
1. Attach the saw blade guard to the mounting bracket
and align the screw holes on the saw blade guard to
the screws on the mounting bracket.
2. Tighten screws securely.
WARNING
When using the saw blade, the saw blade guard must
be attached to the mounting bracket.
Installing the saw blade
See fi gure 8.
WARNING
Be certain all knobs and fasteners are fully tightened
before operating the product. Periodically check for
tightness during use to avoid serious injury.
English (Original instructions)
GRASS TRIMMER TO
Note that the blade nut is a nylon nut, which is to be
used for one time assembly only. Do not reuse the
nylon nut. When installing/reinstalling, use a new nylon
nut. Failure to follow this procedure can result in serious
injury.
To reduce the risk of injury, keep the blade protector on
the blades at all times. Remove the blade protector only
during cutting operations.
1. Centre the blade on the upper fl ange washer and make
sure the blade sits fl at. Install the cupped washer and
make sure it sits well into the gear shaft. Install blade
washer with the raised centre away from the blade.
2. Install the blade nut.
3. Place the Allen wrench through the hole in the upper
fl ange washer and the hole in the gear head. Using the
wrench, turn the blade nut counterclockwise to tighten
(20 Nm).
Make sure the saw blade is in correct position. When
installing the saw blade, the silkscreen on the blade is
always on the top and towards the saw blade guard.
CONVERTING FROM BRUSHCUTTER (SAW BLADE)
TO GRASS TRIMMER
Removing the saw blade and saw blade guard
See fi gure 9.
1. Stop the engine.
2. Place the Allen wrench through the hole in the upper
fl ange washer and the hole in the gear head. Turn the
blade nut clockwise to remove.
3. Remove the blade nut, blade washer, cupped washer,
saw blade, and saw blade guard and retain for later
use.
NOTE: Store the disassembled parts together for later
use.
Installing the ReelEasy™ grass trimmer head
See Figure 9.
1. Install the drive connector and string head housing
into the gear shaft. Place the Allen wrench through the
hole in the upper fl ange washer and the hole in the
gear head. Using the wrench, turn the drive connector
counterclockwise to tighten securely.
2. Reinstall the spool. For the straight shaft attachment
with the ReelEasy™ grass trimmer head, the spool
should be placed so the
3. Replace the bump knob by inserting it into the centre
22
WARNING
WARNING
is visible on the line spool.
