DESCRIPTION
1. Power head
2. Strap hanger
3. Bike handle
4. Shaft
5. Cutting attachment guard
6. Tri-Arc™ blade
7. ReelEasy™ grass trimmer head
8. Bike handle lock knob
9. Quick release tab
10. Latch
11. Mounting bracket
12. Screw
13. Wrench
14. Allen wrench (5 mm)
15. Hole in the gear case
16. Hole in the upper fl ange washer
17. Upper fl ange washer
18. Blade washer
19. Cupped washer
20. Gear head
21. Wrench
22. Drive connector
23. String head housing
24. Spring
25. Gear shaft
26. Spool
27. Knob
28. String head cover
29. Best cutting area
30. Dangerous cutting area
31. Direction of cutter rotation
32. Ignition switch
33. Throttle trigger
34. Throttle lock
35. Throttle interlock
36. Primer bulb
37. Choke lever
38. Tri-Arc™ blade protector
39. Air fi lter knob
40. Air fi lter cover
41. Filter
42. Harness
43. Saw blade
English (Original instructions)
44. Saw blade guard
45. Saw blade protector
46. Shaft hole engine
47. Blade nut
48. Grass defl ector
49. Blade guard
50. Guard screw
51. Starter bit
52. Electrical starter
53. F/R button
54. Starter bit shaft
55. Switch button
ASSEMBLY
UNPACKING
The product requires assembly.
■ Carefully remove the tool and any accessories from
■ Inspect the tool carefully to make sure no breakage or
■ Do not discard the packing material until you have

PACKING LIST

■ Grass trimmer/brushcutter x 1
■ ReelEasy™ grass trimmer head x 1
■ Cutting attachment guard x 1
■ Tri-Arc™ blade x 1
■ Harness x 1
■ Operator's manual x 1
■ Engine oil x 1
■ Combination wrench x 1
■ Wrench x 1
■ Allen wrench (5 mm) x 1
■ Allen wrench (4 mm) x 1
■ Saw blade x 1 (RBC52FSBOS)
■ Saw blade guard x 1 (RBC52FSBOS)
If any parts are damaged or missing, do not operate the
product until the parts are replaced. Failure to heed this
warning could result in serious personal injury.
19
the box. Make sure that all items listed in the packing
list are included.
damage occurred during shipping.
carefully inspected and satisfactorily operated the tool.
WARNING
