3.3
Mounting the rear light
A
B
1. Remove the rear wheel.
2. Insert the plug for the cable gland into the hole in the mudguard (A).
3. Insert the light cable through the cable gland (A).
4. Guide the cable through one of the cavities to the mounting point of the light (A).
5. Fix the cable in several places with the included cable clips (B).
6. Mount the rear light according to the instructions of the respective manufacturer.
→ Only rear lights with a bolt spacing of 20 mm can be fitted.
7. Mount the rear wheel and check that it is securely fitted.
→ No part must touch the tyre.
→ All parts must have a minimum distance of 10 mm to the tyre.
→ The light cable must lie in one of the cavities around the entire circumference of the mudguard.
All manuals and user guides at all-guides.com
A
B
C
Ø 5 mm
C
17
