Engine Wiring Components

Ref. Description
1 Electronic control board
2 Engine outputs
3 Engine sensor inputs
4 Emergency stop, canbus, and
contact outputs
5 Fuses
6 Hour meter
7 Shunt trip relay
8 Contact inputs
13 21 position connector
14 Start relay
15 Alternator / charge
16 B+ switched
17 Crank delay
18 Fuel level
19 Remote start
20 Emergency stop switch
wc_tx000998gb.fm
Ref. Description
21 Toggle switch
22 10A fuse
23 Main breaker
24 Lug door safety switch
25 Mechanical lugs
26 Relay (if equipped)
27 Intake heater (if equipped)
28 Starter relay
29 Starter
30 Alternator
31 12V battery
32 Battery disconnect switch
33 John Deere engine ECU
34 Engine harness
35 Terminal block
36 Resistor (if equipped)
