4.1.2 Information frames on device configuration

When switching to operating mode (PARK or COMMAND mode output), the following frame (0x10) representing the application configuration
of the device is transmitted:
0 1
Code Statut
FR
0x10 Cf Statut
0x10 0xA0
Its size is 10 bytes.
Description of the frame:
EN
Bytes 2 and 3: register 300, transmission period of the Keep Alive frame
Bytes 4 and 5: register 301, period of transmission of the periodic data in number of backups (history logs) to be carried out before transmis-
sion of a frame
Bytes 6 and 7: register 320, backup period: number of readings to be made before making a backup (history logs).
Bytes 8 and 9: register 321, data acquisition period (reading period)
In the example in grey, this results in:
Bytes 2 and 3: S300 = 0x21C0 i.e. 8640 in decimal, the transmission period of the keep alive frame is equal to 8640x10 = 8640sec i.e. 24h.
Bytes 4 and 5: S301 = 0x0008 i.e. 3 in decimal
Bytes 6 and 7: S320 = 0x0002 i.e. 2 in decimal
Bytes 8 and 9: S321 = 0x012C i.e. 300 in decimal
In the example the device will take a reading every 10 minutes (300 seconds), will make a backup every 2 readings every 20 min. (2x10 min
= 20 min) and send a data frame every hours (3 x 20 min = 1 hour).

4.1.3 Information frame on configuration of Digital Input(s)

The 0x1F frame is sent at the start-up of the device (except when it is a reboot after a downlink).
0 1
Code Status
0x1F Cf Status
0x1F 0xA0
Description of the frame:
Bytes 2: register 380, configuration of the button alarm (Digital Input 1)
Bytes 3 and 4: register 381, configuration of the threshold of the alarm button (Digital Input 1)
Byte 5: register 382, configuration of the alarm of the terminal block (Digital Input 2)
Bytes 6 and 7: S383 register, configuration of the terminal alarm threshold (Digital Input 2)
In the example in grey, this results in:
Byte 2: S380 = 0x41, the device will wait for a buffer period of 100 ms before sending an high change of state detection
Bytes 3 and 4: S381 = 0x0001, i.e. 1 in decimal, the device will send an alarm each time a button is detected
Byte 5: S382 = 0x41, the device will wait for a buffer period of 100 ms before sending an high change of state detection
Bytes 6 and 7: S383 = 0x0001, i.e. 1 in decimal, the device will therefore send an alarm for each detection on the terminal block.
In the example, as soon as a button press (Digital Input 1) is detected (pressure longer than 100ms), an alarm frame linked to the button will be
sent. Same for the terminal block input (Digital Input 2).
2 et 3 4 et 5 6 et 7
PAYLOAD
S300 S301 S320
0x21C0 0x0003 0x0002
2 3 et 4
PAYLOAD
S380 S381 S382
0x41 0x0001 0x41
