1.5.3 Digital input interfaces

The schematic diagram of the digital input interfaces is as follows:
FR
EN
Maximum absolute values
Minimum input voltage
Maximum input voltage
Electrical Characteristics
Minimum input voltage
Maximum input voltage
Equivalent input resistance
Input frequency
Current consumption input level HIGH
Current consumption input level LOW
Values above the absolute maximum values will damage the device.

1.5.4 Characteristics of integrated sensors

Characteristics
Temperature
Humidity
- 0,7
+50
0
24
500
10
0
6
Range -20/+60
+/- 0.4 between [0-60°C]
Accuracy
+/- 1 between [-20-0°C]
Resolution +/- 0.02 à 25°C
Range 10 - 90
Accuracy +/- 2
Resolution 0.1 at 25°c
