5 Usage

5.1 General operating information

CAUTION!
If the lifting straps are guided incorrectly in the hoist
(e.g. the straps become twisted), the ceiling hoist will
automatically turn off.
– Keep the straps straight to ensure they feed into the
hoist correctly. The straps are held taught by the
weight of the hooks.
– Keep the straps freely suspended when the unloaded
hoist is lifting/lowering.
If a user unintentionally traps the hand in the lifting strap
during lifting, the hoist will automatically turn off. The
hoist stops immediately when a hand gets in contact
with the strap inlet.
– Keep your hands away from the strap inlet during
lifting.
CAUTION!
The hand control is protected against splashed water
(IPX4). Extended contact with water will damage the
hand control.
– Do not immerse the hand control in liquids, even for a
short time.
– Avoid any contact with water or other liquids.
1586745-B

5.2 Operating the ceiling hoist

The ceiling hoist is in operation mode as soon as a button on the
hand control is pressed.
A
B
Lifting and lowering the straps
When the ceiling hoist is not loaded, it will lift/lower at
high speed. When loaded with more than 10 kg, the
lifting/lowering speed is automatically reduced to a safe level.
To lift the straps, press the UP button A on the hand control.
1.
To lower the straps, press the DOWN button B on the hand
2.
control.
The ceiling hoist can also be operated by pressing the UP
and DOWN buttons on the underside of the hoist.
Traverse Robin™along the track
1. Use the two lifting straps to pull the ceiling hoist along the track.
DO NOT use the red emergency strap to traverse the
ceiling hoist.
Usage
A
B
C
D
13
