Invacare ® Robin™

10 Technical data

10.1 Dimensions and weight

Dimensions
Hoist length (A)
Hoist width (B)
Hoist height (C)
Maximum lifting range (D)
Weights
Maximum lifting capacity (Safe
Working Load)
Total weight without sling
26
Robin
Robin™
Mover™
470 mm 470 mm
250 mm 250 mm
203 mm 266 mm
2.5 m 2.5 m
Robin
Robin™ Mover™
200 kg 200 kg
7.3 kg 10 kg

10.2 Electrical System

Robin™
Maximum current
input
1
Protection class
(ceiling hoist: IP24; hand control: IP44)
Insulation class
Applied part complying with the specified
requirements for protection against electrical
shock according to IEC60601-1.
Sound level
Number of lifts per
charge
Intermittent
(periodic motor
operation)
Battery
Charging time
Lifting speed with
2.1 cm/s
200 kg load
Traverse speed in
the tracks
Robin Mover™
0.9 A
Entire device: IPx4
Class II equipment
Type B applied part
50 – 55 dB (A)
65 lifts of 0.5 m with 80 kg
10%, max. 2 min. / 18 min.
NiMH Battery 24V / 2.0 Ah
Up to 3 hours at 20°C
2.1 cm/s
n/a 14 cm/s
1586745-B
