eng
9. When the desired thread length is reached, release the safety tip switch (8).
10. When the unit stops rotating turn the rotation lever (7) into reverse. The quick-
change die head (1) is run off the thread by pressing the safety tip switch (8)
again.
NOTICE
Only change the direction on the rotation lever (7) when the unit stops rotating!
3.2. Production of nipples and double nipples
For clamping short pieces of pipes and for the production of nipples and double
nipples use REMS Nippelspanner. They are available in sizes from ⅜ to 2" For
clamping pipe pieces (with or without thread) with the REMS Nippelspanner
the head of the Nippelspanner is expanded by turning the spindle (21) with a
tool (e.g. screwdriver). This must only be done when a pipe is put on (Fig. 5).
When using the REMS Nippelspanner it must be observed that no shorter
nipples are threaded than specified in the standards.
4. Maintenance
4.1. Maintenance
WARNING
Pull out the mains plug before maintenance work!
Clean the drive unit and die head seat regularly especially when this has not
been in use for a long time.
5. Faults
5.1. Fault: Electric die stock does not pull through, overload protection (10) triggers off.
Cause:
● Not original REMS quick-change die heads.
● REMS dies are blunt.
● Unsuitable thread-cutting material.
● Worn carbon brushes.
● Mains lead defective.
● Electric die stock defective.
5.2. Fault: No workable thread, threads are ripping off.
Cause:
● REMS dies are blunt.
● REMS dies inserted incorrectly.
● Unsuitable or insufficient thread-cutting material.
● Pipe material is unsuitable for thread cutting.
5.3. Fault: Thread is cut skew to the pipe axis.
Cause:
● Pipe not cut at a right angle.
5.4. Fault: Pipe slips in support bracket (2).
Cause:
● Pipe not clamped tightly enough in support bracket.
● Prismatic clamping jaw (3) heavily soiled.
● Teeth of the prismatic clamping jaw (3) worn.
5.5. Fault: Die stock hits the support bracket (2).
Cause:
● Support bracket fixed too close to the end of the pipe or rod.
● Long thread cut without re-tightening.
5.6. Fault: Electric die stock does not start.
Cause:
● Rotation ring/lever (7) not snapped into position.
● Overload protection (10) has triggered (REMS Amigo, REMS Amigo 2
Compact).
● Worn carbon brushes.
● Mains lead defective.
● Electric die stock defective.
12
Clean heavily soiled REMS quick-change die heads (1) with turpentine oil for
example and remove stuck chips. Clean the drive unit and the holder of the
REMS quick-change die heads from time to time.
Clean plastic parts (e.g. housing) only with REMS CleanM machine cleaner
(Art. No. 140119) or a mild soap and a damp cloth. Do not use household
cleaners. These often contain chemicals which can damage the plastic parts.
Never use petrol, turpentine, thinner or similar products for cleaning.
Make sure that liquids never get onto or inside the drive unit. Never immerse
the drive unit in liquid.
4.2. Inspection/repair
WARNING
Pull out the mains plug before carrying out maintenance or repair work!
This work may only be performed by qualified personnel.
The gear runs in a life-long grease filling and therefore needs no lubrication.
The drive machine motor has carbon brushes. These are subject to wear and
must therefore by checked and changed by qualified specialists or an author-
ised REMS customer service workshop from time to time.
Remedy:
● Only use REMS quick-change die heads.
● Change REMS dies, see 2.3.
● Use REMS Spezial or REMS Sanitol thread-cutting oils.
● Have the carbon brushes changed by qualified personnel or an authorised
REMS customer service workshop.
● Have the mains lead replaced by qualified personnel or an authorised REMS
customer service workshop.
● Have the electric die stock checked/repaired by an authorised REMS customer
service workshop.
Remedy:
● Change REMS dies, see 2.3.
● Observe numbering of the REMS dies to the slot number of the die head body
(18), see 2.3, change die heads if necessary.
● Use sufficient, undiluted quantity of REMS Spezial or REMS Sanitol thread-
cutting oil, see 3.1.
● Only use approved pipes.
Remedy:
● Cut pipe at right angle, e.g. with dual purpose holder (Art.-No. 543100,
accessory) Fig. 7 and REMS Tiger ANC, REMS Tiger ANC VE, REMS Tiger
ANC SR or with REMS RAS St, REMS Turbo K, REMS Cento.
Remedy:
● Make the clamping spindle (4) tighter.
● Clean the prismatic clamping jaw with a wire brush for example.
● Change the support bracket (2).
Remedy:
● Fix the support bracket about 10 cm from the end of the pipe or rod, see 3.1.
● Switch the electric die stock off when it approaches the support bracket.
Remedy:
● Snap in the rotation ring/lever.
● Wait a few seconds then press the button of the overload protection.
● Have the carbon brushes changed by qualified personnel or an authorised
REMS customer service workshop.
● Have the mains lead replaced by qualified personnel or an authorised REMS
customer service workshop.
● Have the electric die stock checked/repaired by an authorised REMS customer
service workshop.
