Intended use

The OneSystem Security Lock 309N / 319N is suitable for installation in single or
double-leaf tubular frame or solid-leaf doors (backset 55 mm or greater) made of
metal or wood.
It is designed to provide door locking in security areas and is approved for use
in escape doors according to DIN EN 179 and panic door locks according to
DIN EN 1125.
· With two-leaf escape doors, the inactive leaf must also be designed as an escape
door and must be equipped with an approved passive leaf lock.
· If the inactive leaf is not designed as an escape door, the OneSystem Security Lock
309N / 319N may only be installed in the two-leaf door when the inactive leaf
can be securely held in place with zero play and the active leaf runs against a
stop edge.
With double-leaf doors with rebated meeting stile and panic locks in each leaf,
the leaf must open when the panic door lock is actuated. Both leaves must open
freely if both panic door locks are actuated at the same time. This may require a
door coordinator to be installed.
With double-leaf doors with rebated meeting stile and door closer, the correct
door closing sequence must be assured; otherwise the function of fire doors or
smoke protection doors, in particular, is not guaranteed. It may be necessary to
install a follower.
It is approved for use in fire doors (smoke protection doors). All applicable
provisions for the approval of protective doors must be observed.
.The OneSystem Security Lock 309N / 319N may only be installed in properly
functioning door systems. All applicable regulations for the complete door
system must be observed.
The device is suitable for installation according to the installation instructions and
use according to the functional description.
The OneSystem Security Lock 309N / 319N is suitable for installation in doors with a
high usage frequency, for use by persons with little reason to take care, where
there is the possibility of an accident or misuse (such as office doors).
It is not intended for any other type of use.
