B
(Figura 13)
D
E
B
C
(Figura 14)
78 - EB140 / Operating instructions
A

4.3.2 Releasing the glue applicator roller

(Figure 13)
Loosen screw A, push transport lock C until the stop for glue
applicator D reaches the end.
This safety catch has been set for the machine transport.
If you wish to repeat the trimming of a board with an edge
that already has been banded, you must lock the roller again
in its initial transport position.

4.4 PRIOR ASSEMBLY

4.4.1 Assembling the flywheel

(figure 14)
Remove cover A from flywheel B. Mount the flywheel in pla-
ce, matching up the key slot with key C, and attach it with
screw D and washer E, using the service spanner.
Finally, replace cover A.
A
C
D
