Aquatec® Ocean VIP / VIP XL / Dual VIP

10 Technical data

10.1 Dimensions and weight

B
L
J
C K
H G
E
Model Ocean VIP
Dimensions [mm] and weight [kg]
A
B
C
D 595
E
F
G
H
24
M
F
A
Ocean VIP Ocean Dual
XL VIP
500
450
510 – 610
625 625
106
1085 – 1185
845
160
Model
Ocean VIP
I
J
K
420 – 520 (with toilet pan holder)
440 – 540 (without toilet pan holder)
L
M
475
Width,
hygiene recess
Depth,
hygiene recess
Angle of
inclination
seat
Angle of
-
inclination
backrest
Caster
diameter
Product
23.5
weight
Minimum /
Maximum
User weight
Ocean VIP Ocean Dual
XL VIP
720 – 860
345 – 465
215 / 245
555 475
205
320
0° – 35°
-
10° – 50°
5" (127 mm)
23.5 28.3
40 / 150
