Swivelling the seat frame with backrest

IMPORTANT!
– Only use the removable handle and only swivel the
seat frame with backrest if a user is sitting on the
commode.
– On swiveling the seat frame with backrest, pull the
backrest backwards or forwards using the handle.
– Never reach into the area between the seat frame
with backrest and the front tubular frame between
the side sections when swivelling.
– Do not drive when the seat frame of the backrest is
swivelled.
Swivelling backwards/forwards
The seat frame can be tilted approx. 35° backwards together
with the backrest.
1. Pull the removable handle D and hold it in this position. The
distributor C is used to release the blocking of the pneumatic
springs B.
Press the seat frame A at the handle of the backrest E
2.
backwards or forwards together with the backrest. The
pneumatic springs B are extended or retracted.
3. Release the removable handle. The seat frame is fixed at the
currently set inclination.
1563142-B
Swivelling forwards without a user
1. Stand next to the commode.
2. Pull the removable handle with one hand and keep in this
position.
3. Press the seat frame with backrest down by pushing the middle
of the seat surface with your other hand.
4. Release the removable handle once the seat frame with backrest
is swivelled forwards. The seat frame is now fixed in this position.
