Invacare® Cadiz
WARNING!
Risk of falling
– Make sure that both snap buttons H of the
backrest tubes fully engage in the holes of the
seat tubes with an audible click.
Adjusting the seat height (Fig. 4)
The height of the seat can be adjusted between 405
and 505 mm in five steps of 25 mm.
1. Place the seat upside down on a clean, flat and stable
surface (floor or table). Make sure that the seat plate
is not damaged.
2. Press the snap button A of the legs and slide the leg
extension up or down to the desired adjustment hole B.
WARNING!
Risk of falling
– Make sure that all four legs are adjusted to the
same height, see Fig 5.
– Make sure that all four snap buttons engage in
the leg holes with an audible click, see Fig 5.
Usage
Safety information
WARNING!
Risk of injury
– All four leg tips must be in contact with
shower/tub floor at all times and on an even
surface.
– Always inspect the shower chair to ensure that
it is properly positioned and stable before using.
Do not use the shower chair if it is wobbly or
unstable.
– Users with limited physical or mental capabilities
should be supervised or assisted when using
the shower chair.
WARNING!
Risk of injury and damage due to backrest getting
loose.
– Do not lift the shower chair for re-positioning
or transfer while seated.
– Do not use the backrest as a supporting aid.
CAUTION!
Risk of burning your skin
The product components can heat up when
exposed to external sources of heat.
– Do not expose the product to strong sunlight
before use.
– Allow the product to reach room temperature
before use.
Maintenance
Cleaning and disinfection
The product can be cleaned and disinfected using
commercially available agents.
IMPORTANT!
In the sensitive area of the bathroom, hygiene is
particularly important.
– Keep the product clean at all times and wash
it regularly.
4
Before using any cleaning products, test an area on
the underside of the seat to make sure the product
does not cause discoloration or staining.
1. Remove the legs and backrest from the shower chair.
2. Use water and a mild, non-abrasive cleaner to clean the
shower chair.
3. Disinfect the product by wiping down all generally
accessible surfaces with disinfectant.
IMPORTANT!
All cleaning agents and disinfectants used must
be effective, compatible with one another and
must protect the materials they are used to clean.
For further information on decontamination in
Healthcare Environments, please refer to 'The
National Institute for Clinical Excellence' guidelines
on Infection Control www.nice.org.uk/CG139 and
your local infection control policy.
– Clean by hand.
– Clean without scouring agent.
– Max. cleaning temperature 85 °C for 3 min.
CAUTION!
Risk of burning your skin
– Allow the product to cool after cleaning.
After Use
Re-use
The product is suitable for repeated use. The number of
times it can be used depends on how often and in which
way the product is used. Before reuse, clean and disinfect
the product thoroughly and check the safety functions, and
reset if necessary.
Disposal
The disposal and recycling of used devices and packaging
must comply with the applicable local legal regulations.

Technical Data

Dimensions and weight (Fig. 6)
H291
–
A
450 – 550 mm
B
C
D
E
F
G
H
I
2.4 kg
H296
775 – 875 mm
–
310 mm
405 – 505 mm
395 – 405 mm
465 – 480 mm
510 mm
230 mm
400 mm
3 kg
143 kg
1637297-A
