Technical Specifications
12.1
Pump key
1. Electrical version
E 10 = on/off switch, mechanical stroke adjustment
E 11 = similar to E 10, but with the addition of empty signal with low level advanced warning
E 20 = on/off/test switch, mechanical stroke adjustment, pulse input, empty signal with low level
advanced warning, empty signal output, stroke signal output
individual stroke control (each stroke is executed completely)
E 1 0 0 0 0 0 9 P V 1 0 F P K E P V 9 9
417101338_EMPKKS.doc
2. Pump output 50 Hz
00002
=
00005
=
00009
=
00014
=
3. Pump head material
PV = PVDF
4. Metering backpressure (not freely selectable)
10
= 10 bar s
5. Gasket material
FP
= Viton B
EP = EPDM
KA = Kalrez
6. Ball material
KE = Ceramic
GL = Glas
7. Valve material
PV = PVDF
8. Valve spring
99
= without spring
9. Mains power supply
01
= mains power cable 2 m
02
= 3-core mains power cable 2.4m cable end sleeves
09
= mains power cable, US version
10
= appliance plug
13
= mains power cable, Italian version
10. Voltage/frequency
01
= 115V / 50 Hz
02
= 115V / 60 Hz
03
= 230V / 50 Hz
0 1
0 3
04
= 230V / 60 Hz
63
(60 Hz)
0,2 l/h
(0,24 l/h)
0,5 l/h
(0,6 l/h)
0,9 l/h
(1,1 l/h)
1,4 l/h
(1,7 l/h)
(standard)
(8 bar)
(standard)
(Standard)
(standard)
(standard)
(Standard)
(standard)
Rev: 08-01.10
