1.
Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer,
We hope your new product brings you much enjoyment
and success.
Note:
In accordance with the applicable product liability laws,
the manufacturer of this product assumes no liability
for damage to the product or caused by the product
arising from:
• Improper handling
• Non-compliance with the operating manual
• Repairs carried out by third parties, unauthorised
specialists
• Installing and replacing non-original spare parts
• Improper use
Note:
The operating manual is part of this product.
It includes important instructions for the safe, proper
and economic operation of the product, for avoiding
danger, for minimising repair costs and downtimes and
for increasing the reliability and extending the service
life of the product. In addition to the safety instructions
in this operating manual, you must also observe the
regulations applicable to the operation of the product
in your country.
Familiarise yourself with all operating and safety in-
structions before using the product. Only operate the
product as described and for the specified areas of ap-
plication. Keep the operating manual in a good place
and hand over all documents when passing the product
on to third parties.
2. Product description (fig. 1 - 13)
1.
Drive lever (cutter bar)
1a. Lock nut (cutter bar Bowden cable)
1b. Lock nut (cutter bar Bowden cable)
1c. Switch-on safety device (cutter bar)
2.
Handle
3.
Throttle
3a. M8 hexagonal nut
4.
Fuel filler cap
5.
Engine
6.
Air filter cover
6a. Air filter insert
7.
Wheel
7a. Axle cover
7b. Pin
8.
Cutter bar
8a. M8 x 25 mm hexagonal bolt
8b. M8 hexagonal nut
8c. Levelling plate
8d. M8 hexagonal nut
8e. Skid
9.
Belt cover
9a. M8 x 25 mm flange screw
9b. Washer
10. Guide bar
10a. Hexagonal bolt
10b. Washer
10c. Hexagonal nut
11. Height adjustment
11a. M8 x 25 mm hexagonal bolt
11b. M8 hexagonal nut
12. Steering
13. Drive lever (wheels)
13a. Lock nut (travel drive Bowden cable)
13b. Lock nut (travel drive Bowden cable)
14. Oil filler plug (with scale)
15. Oil drain screw
16. Pull starter
17. Spark plug
3. Scope of delivery
Item
3
3 a
7
7 a
7b
8
8 a
8b
9
9 a
10
www.scheppach.com
Quantity
Designation
1x
Throttle
2x
M8 hexagonal nut
2x
Wheel
2x
Axle cover
2x
Pin
1x
Cutter bar
1x
Blade guard (not shown)
4x
M8x25 mm hexagonal bolt
4x
M8 hexagonal nut
1x
Belt cover
1x
M8x25 mm flange screw
1x
Guide bar
GB | 29
