Global Settings
Press the
button and use the
global
through and set parameters such as Master Tune and MIDI Channel that
affect all programs globally.
1. Master Coarse Tune: -12...+12—
centered. Steps in semitones up to one octave up (+12) or down (-12).
2. Master Fine Tune: -50...+50—
Steps in cents as much as a quarter-tone up (+50) or down (-50).
3. MIDI Channel: All, 1...16—
receive data, 1 to 16. Choosing
4. MIDI Clock Mode:
MIDI clock messages:
•
Off: MIDI Clock is neither sent nor received
•
Master: MIDI Clock is sent, but not received.
•
Slave: MIDI Clock is received, but not sent.
•
Slave Thru: MIDI Clock is received and passed to MIDI Out
•
Slave No S/S (no start and stop): Receives MIDI Clock but does not
respond to MIDI Start or Stop command.
In Slave and Slave Thru modes, if no MIDI clock is present at the selected
input, the arpeggiator and sequencer will not function.
5. MIDI Clock Cable: MIDI Port, USB—
which MIDI clocks are received.
6. MIDI Param Send: Off, CC, NRPN—
panel controls are transmitted via MIDI as Non-registered Parameter
Number (NRPN) controllers or as Continuous Controllers (CC). Trans-
mission of parameters can also be turned off. See MIDI Implementation
on page 79 for details.
NRPNs are the preferred method of parameter transmission, since they cover
the complete range of all parameters, while CCs are limited to a range of 128.
14
Global Settings
parameter
Master Transpose control, 0 is
Master Fine Tune control; 0 centered.
Selects which MIDI channel to send and
receives on all 16 channels.
all
Sets the synthesizer's ability to send and receive
Sets the port, MIDI or USB, by
Changes to the values of front
and
knobs to scroll
value
Dave Smith Instruments
