Connections
1
1. AC Power Connector—
cord. Operates over a range of 100 to 240 volts and 50 to 60 Hz.
For bidirectional MIDI communication with a computer. The
2. USB—
Prophet Rev2 is a Class Compliant USB device and does not require
additional drivers when used with Mac OS or Windows. See Using USB
on page 67 for more information.
3. MIDI In, Out, and Thru—
Accepts a momentary, normally open or normally closed
4. Sequencer—
footswitch to turn the sequencer or arpeggiator on and off. Alternatively, an
audio signal connected to this jack can be used to either control sequencer/
notes are held. See Pedal/CV on page 13 for more information about
choosing the appropriate mode for these behaviors.
Audio signals used to drive the arpeggiator/sequencer should not exceed 5
volts peak-to-peak.
Accepts a momentary, normally open or normally closed
5. Sustain—
footswitch to control sustain.
12 Connections
Accepts a standard, grounded IEC power
Standard 5-pin MIDI DIN connectors.
2 3
Dave Smith Instruments
PEDAL/CV
4 5 6
B
