Appendix E: MIDI Implementation
The Prophet Rev2 receives MIDI data according to the settings you have
chosen in
. In addition, there is interaction between some of the
globals
program parameters that determine the overall response of Prophet Rev2
to MIDI data. Following are the
to MIDI:
MIDI Channel: All, 1...16—
receive data, 1 to 16. All receives on all 16 channels.
Sets the Prophet Rev2's ability to send and receive
MIDI Clock Mode:
MIDI clock messages:
•
Off: MIDI Clock is neither sent nor received
Master: MIDI Clock is sent, but not received
•
•
Slave: MIDI Clock is received, but not sent
Slave Thru: MIDI Clock is received and passed to MIDI Out
•
•
Slave No S/S (no start and stop): Receives MIDI Clock but does not
respond to MIDI Start or Stop command.
When set to
slave
the arpeggiator and sequencer will not function.
MIDI Clock Cable: MIDI Port, USB—
which MIDI clock signals are received.
MIDI Param Send: Off, CC, NRPN—
controls are transmitted via MIDI as Continuous Controllers (CC) or
Non-Registered Parameter Number (NRPN). Transmission of parameters
can also be turned off.
NRPNs are the preferred method of parameter transmission, since they cover
the complete range of all parameters, while CCs are limited to a range of 128.
Param Rcv: Off, CC, NRPN—
are received via MIDI. As with transmission, NRPNs are the preferred method.
Prophet Rev2 User's Guide
parameters that affect response
globals
Selects which MIDI channel to send and
or
, if no MIDI clock is present at the selected input,
slave thru
Sets the port, MIDI or USB, by
Changes to the values of front panel
Sets the method by which parameter changes
Appendix E: MIDI Implementation
79
