PEDAL/CV
2 3 4 5
6. Pedal/CV—
resistor on a TRS (tip-ring-sleeve) ¼ inch phone plug. Once connected,
you can use the modulation matrix to route the pedal to control a variety
to live performance.
7. B Audio Outputs—
cables to these jacks if you want separate stereo outputs for Layer B. If
no cables are connected, Layer B is output on the Main A Outputs.
8. Main/ A Audio Outputs—
are the main stereo outputs for the synth. They carry Layer A and also
Layer B if no cables are connected to the "B Audio Outputs" jacks.
9. Headphones—
controlled by the
Prophet Rev2 User's Guide
B OUTPUT
6 7
Accepts a standard expression pedal that has a variable
Unbalanced, ¼ inch audio outputs. Connect audio
Unbalanced, ¼ inch audio outputs. These
A ¼ inch stereo headphone jack. Headphone volume is
master volume
MAIN A OUTPUT
8 9
knob on the front panel.
Connections 13
