8) Technical characteristics
Nice S.p.a., in order to improve its products, reserves the right to modify their technical characteristics at any time without prior notice.
In any case, the manufacturer guarantees their functionality and fitness for the intended purposes.
All the technical characteristics refer to a room temperature of 20°C (±5°C).
Technical characteristics: ROAD200
Type
Pinion
Peak thrust
Nominal torque
Idling speed
Nominal torque speed
Maximum frequency of operating cycles
Maximum continuous operating time
Operating limits
ROAD200 Power supply
ROAD200/V1 Power supply
Max. absorbed power
Insulation class
Flashing light output
STOP input
Step-by-step Input
Radio AERIAL Input
Radio receiver
Programmable functions
Recognition functions
Operating temperature
Use in acid, saline or potentially explosive
atmosphere
Protection class
Dimensions and weight
Technical characteristics:
Type
Frequency
Coding
Transmitter compatibility (1)
Transmitters memorized
Input impedance
Sensitivity
Range of the transmitters
Outputs
Operating temperature
Note 1: the first transmitter introduced also determines the type of transmitters that can be introduced afterwards
Electromechanical gearmotor for the automatic movement of residential sliding gates
including electronic control unit.
Z: 15; Module: 4; Pitch: 12.5 mm; Pitch diameter: 60mm
6Nm; corresponds to the ability to start a leaf with a static friction of max. 200N moving.
3.3Nm; corresponds to the ability to keep a leaf with a dynamic friction of max. 110N moving
the control unit allows 2 speeds to be programmed, equal to: 0.14m/s or 0.26m/s
30 cycles per day (the control unit allows up to the maximum described in tables 1 and 2)
7 minutes (the control unit limits the continuous operation up to the maximum described in
tables 1 and 2)
In general, ROAD200 is suitable for the automation of gates featuring leaves up to 5 m
wide and weighing up to 200 kg, as shown in Tables 1 and 2.
For 1 LUCYB flashing light (12V, 21 W lamp)
For normally open contacts, for 8.2Kohm constant resistance, or normally closed contacts;
with self-recognition (any variation from the memorized status causes the 'STOP'
command)
For normally open contacts (the closing of the contact causes the "STEP-BY-STEP" command)
2 ON-OFF functions and 3 adjustable functions (see tables 12 and 14)
Recognition of the type of "STOP" device (Normally Open or Normally Closed contact or
8.2KΩ resistance). Recognition of the length of the gate and calculation of the slowdown
and partial opening points.
incorporated radio receiver
4 channel transmitter for incorporated radio command
Digital fixed code with 12 Bit code, FLO type
Digital Rolling code with 52 Bit code, FLOR type
Digital Rolling code with 64 Bit code, SMILO type
FLOR, VERY VR; only single group: ERGO, PLANO, PLANOTIME
Up to 160 if memorized in mode 1
From 100 to 150 m. The range can vary if there are obstacles or electromagnetic disturbances,
and is affected by the position of the receiving aerial
For commands as of table 4 and 5
0.26m/s;
0.18m/s
230Vac (+10% +15%) 50/60Hz.
120Vac (+10% +15%) 50/60Hz.
150W (0.9A)
1 (a safety grounding system is required)
52 ohm for RG58 or similar type of cable
Incorporated
-20°C ÷ 50°C
No
IP 44
330 x 195 h 277; 8Kg
433.92MHz
FLO, VERY VE
SMILO
52Ω
better than 0.5µV
-20°C ÷ 55°C
GB
19
