7.2) Programming
A number of programmable functions are available on the ROAD200
control unit. The functions are adjusted using 2 buttons set on the
control unit: [▲▼] and [Set] and are used by means of 3 LEDs: L1,
L2, L3.
The programmable functions available on ROAD200 are set out on
2 levels:
Level one: the functions can be adjusted in modes ON-OFF (active or
inactive). In this case, each of the LEDs L2....L3 indicates a function.
7.2.1) Level one functions (ON-OFF functions).
Table 13: programmable function list: Level one:
LED Function
L1
---
L2
Motor speed
L3
Automatic Closing
During the normal functioning of ROAD200, LEDs L2 and L3 will either be on or off depending on the state of the function they represent.
For example, L3 will be on if the "Automatic Closing" function is active.
7.2.2) Level one programming (ON-OFF functions).
Level 1 functions are all factory set to "OFF". However, they can be changed at any time as shown in Table 14. Follow the procedure care-
fully, as there is a maximum time of 10 seconds between pressing one button and another. If a longer period of time lapses, the procedure
will finish automatically and memorize the modifications made up to that stage.
Table 14: changing ON-OFF functions
1.
Press the button [Set] and hold it down (approx. 3 s)
2.
Release the [Set] button when L1 LED starts flashing
3.
Press button [▲▼] to move the flashing LED onto the LED representing the function which is to be
changed.
4.
Press the [Set] button to change the state of the function (short flashing = OFF; long flashing = ON)
5.
Wait 10 seconds before leaving the programme to allow the maximum time to lapse.
Note: Points 3 and 4 can be repeated during the same programming phases in order to set other functions to ON or OFF.
7.2.3) Level two functions (adjustable parameters)
Table 15: programmable function list: level two
Input LED
Parameter
L1
Motor force
Step-by-step
L2
Function
L3
Pause Time
Note: "
" represents the factory setting.
All the parameters can be adjusted as required without any contraindication; only the adjustment of the "motor force" could require special
care:
• Do not use high force values to compensate for points of abnormal friction on the leaf. Excessive force can compromise the operation of
the safety system or damage the leaf.
• If the "motor force" control is used to assist the impact force reduction system, measure the force again after each adjustment in compli-
ance with EN standard 12445.
• Wear and weather conditions may affect the movement of the gate, therefore periodic re-adjustments may be necessary.
Description
---
This function permits the speed of the motor to be selected between two levels, "fast", "slow".
If the function is deactivated the speed is set on "slow".
This function causes the door to close automatically after the programmed time has lapsed.
The factory set Pause Time is 30 seconds, but can be changed to 15 or 60 seconds (see Table 15).
If the function is inactive, functioning will be "semi-automatic".
LED (level)
value
L1
Low
L2
Medium
L3
High
L1
Open - stop - close - open
L2
Open - stop - close - stop
L3
Condominium operation
L1
15 seconds
L2
30 seconds
L3
60 seconds
If the LED is on, the function is active, if off the function is inactive. See
Table 12. The radio status is displayed by the L1 LED which is used
for the second level function only..
Level two: the parameters can be adjusted on a scale of values
(from 1 to 3). In this case, each of the LEDs L1, L2, L3 indicates the
value set (there are 3 possible settings). Please refer to Table 15.
Adjust the sensibility of the motor force control to suit
the type of gate. The "High" adjustment is more suit-
able for heavier and larger doors.
Manages the sequence of controls associated to the
Step-by-Step input or to the 1st radio command (see
tables 4 and 5).
Adjusts the pause time, namely the time which lapses
before automatic closure. This will only have an effect if
automatic closing is active.
Example
SET
L1
SET
SET
10s
Description
GB
3s
13
