BML SGA-AEZ1-LZZZ- _ _ _1- _ _ _ _
Absolute magnetic encoder system
1

Notes to the user

1.1 Validity
This guide describes the construction, function and
installation options for the BML absolute magnetic encoder
system. It applies to the following models (see Type code
on page 24):
– BML SGA-AEZ1-LZZZ-ZU11-S115
– BML SGA-AEZ1-LZZZ-TU11-S284
The guide is intended for qualified technical personnel.
Read this guide before installing and operating the
magnetic encoder system.
For additional information about the interfaces
please refer to the document Interfaces for
BML Magnetic Encoder.
1.2

Symbols and conventions

Individual actions are indicated by a preceding triangle.
► Instruction 1
Action sequences are numbered consecutively:
1. Instruction 1
2. Instruction 2
Numbers unless otherwise indicated are decimals (e.g.
23). Hexadecimal numbers are represented with a
preceding 0x (e.g. 0x12AB).
Note, tip
This symbol indicates general notes.
1.3

Scope of delivery

– Sensor head BML SGA
– Condensed guide
Magnets are available in various models and
must be ordered separately (see Accessories on
page 22).
1.4

Approvals and markings

UL approval
File no.
E227256
The CE Mark verifies that our products
meet the requirements of the current
EMC Directive.
www.balluff.com
The transducer meets the requirements of the following
product standard:
– EN 61326-2-3 (noise immunity and emission)
Emission tests:
– RF emission
EN 55011
Noise immunity tests:
– Static electricity (ESD)
EN 61000-4-2
– Electromagnetic fields (RFI)
EN 61000-4-3
– Electrical fast transients (burst)
EN 61000-4-4
– Surge
EN 61000-4-5
– Conducted interference induced by
high-frequency fields
EN 61000-4-6
– Magnetic fields
EN 61000-4-8
More detailed information on the guidelines,
approvals, and standards is included in the
declaration of conformity.
1.5

Abbreviations

BML Balluff Linear Magnetic Encoder System
1.6

Additional documents

Additional documents can be obtained online at
www.balluff.com or by e-mailing
service@balluff.de.
Severity level 4
Severity level 3
Severity level 3
Severity level 2
Severity level 3
Severity level 5
english 5
