Selecting the settings for a selected remote camera
 Setting the white balance 
The ratio between RGB (three primary colours) is adjusted
so that white will be reproduced accurately.
If the white balance is off, not only will white be reproduced
poorly but the colour tone of the entire picture will also
deteriorate.
The white balance must be adjusted when using a remote
camera for the first time or when the remote camera has
not been used for a prolonged period of time. It must also
be adjusted when changes have been made in the lighting
conditions or brightness.
The white balance can be adjusted automatically or
manually (fine adjustment after automatic adjustment).
In addition, preset values or the "auto tracking white
adjustment (ATW)" which continues to adjust the white
balance automatically all the time can be selected.
The results of white balance adjustments can be stored
in memory A or memory B when "AWB A" or "AWB B" has
been selected for the white balance.
Selecting the white balance mode
Follow the steps below to set the white balance mode.
1
Set the MENU button to ON.
Press the MENU button to light its indicator.
2
Set the PRESET MEMORY/MENU 4 button
(AWB/ABB) to ON.
When the button is pressed and its indicator lights, the
[AWB/ABB] menu is displayed on the LCD panel.
3
Turn the F1 dial to select the white balance
mode.
AWB MOD:
SET :
All manuals and user guides at all-guides.com
AWB B
AWB
8 (E)
The modes which can be selected differ depending on the
remote camera connected.
Remote
Mode
camera
The status of the white balance
AWB A registered in remote camera
memory A is established.
The status of the white balance
AWB B registered in remote camera
memory B is established.
AW-HE50
In this mode, the white balance is
automatically adjusted continuously
all the time and automatically
ATW
compensated even when the light
source or colour temperature has
changed.
The status of the white balance
AWB A registered in remote camera
memory A is established.
The status of the white balance
AWB B registered in remote camera
memory B is established.
AW-HE100 The status of the white balance
AW-HE870 3200K which was adjusted at a brightness
AW-E860 of 3200K is established.
AW-E750
The status of the white balance
AW-E650
5600K which was adjusted at a brightness
AW-E350
of 5600K is established.
In this mode, the white balance is
automatically adjusted continuously
all the time and automatically
ATW
compensated even when the light
source or colour temperature has
changed.
AK-HC1500

AK-HC1800
Remote camera status

