Setting the functions
Adjusting the minimum lens
zoom start speed
This adjustment ensures that the lens zoom will start moving
smoothly in line with the inclination of the ZOOM button
when operating the lens zoom using the ZOOM button.
From the [SETUP] menu, select [PTZ ADJ] and display
[Z MIN SPEED]. Then turn the F2 dial to set the
compensation amount.
1.Z MIN SPEED
The lowest compensation amount is "1", and the highest is
"8".
No compensation is provided at the "Off" setting.
While observing the images on a monitor, hold down the
ZOOM button slowly, and check whether the lens zoom
starts moving smoothly.
All manuals and user guides at all-guides.com
Off
24 (E)
Exercising external control
over the preset memory data
Preset numbers can be assigned to execute presets for the
selected remote cameras when signals have been input to
the TALLY/GPI input/output connector.
The presets are assigned using the GPI item on the
[SETUP] menu.
[8]GPI
Setting the preset numbers
From the [SETUP] menu, select [GPI], and display
[PRESET CTL1], [PRESET CTL2] or [PRESET CTL3].
Then set the camera number and preset number.
1.PRESET CTL1
CAM100
Any camera number from "CAM1" to "CAM100" or "ALL" can
be selected.
If "ALL" has been selected, it will not be possible to
execute the preset operations for any remote cameras
which have been set to "NoAsign" as the connection
setting.
Refer to "Settings for connection with the remote
cameras" (<Basics> Operating Instructions).
The preset number setting can be established for each GPI
input.
Input1: PRESET CTL1
Input2: PRESET CTL2
Input3: PRESET CTL3
▼
PRE100
