Setting the functions
 Controlling the peripheral 
devices connected to the
remote cameras
When any of the peripheral devices listed below are
connected to the remote cameras, they can be controlled.
• ND filter • Wiper
• AC adapter • Heater, fan
(AW-PS300A) • Halogen lamp
• Defroster
Control is exercised using the FUNCTION item of the
[SETUP] menu.
[6]FUNCTION
Controlling an ND filter
This item is used to control the ND filter when using a lens
with an ND filter function on the currently selected remote
camera.
From the [SETUP] menu, select [FUNCTION] and display
[ND FILTER]. Then select ND filter control.
1.ND FILTER
Controlling an AC adapter (AW-PS300A)
This item is used to control shorting and releasing of the
OPTION SW CONTROL OUT connector when using an
AC adapter (AW-PS300A) for the currently selected remote
camera.
From the [SETUP] menu, select [FUNCTION] and display
[OPTION]. Then select shorting or releasing.
2.OPTION
Controlling a defroster
This item is used to control a defroster when using a remote
camera (AW-PH650 + camera) equipped with a defroster
function as the currently selected remote camera.
From the [SETUP] menu, select [FUNCTION] and display
[DEFROSTER]. Then select defroster On or Off.
3.DEFROSTER
All manuals and user guides at all-guides.com
Off
Off
Off
23 (E)
Controlling a wiper
This item is used to control a wiper when using a remote
camera (AW-PH650 + camera) equipped with a wiper
function as the currently selected remote camera.
From the [SETUP] menu, select [FUNCTION] and display
[WIPER]. Then select wiper On or Off.
4.WIPER
Controlling a heater/fan
This item is used to control a heater/fan when using a
remote camera (AW-PH650 + camera) equipped with a
heater or fan function as the currently selected remote
camera.
From the [SETUP] menu, select [FUNCTION] and display
[HEATER/FAN]. Then select heater/fan On or Off.
5.HEATER/FAN
Controlling a halogen lamp
This item is used to control the lighting (On) and
extinguishing (Off) of the halogen lamp when a halogen
lamp has been connected to the currently selected remote
camera.
From the [SETUP] menu, select [FUNCTION] and display
[LAMP]. Then select halogen lamp lighting (On) and
extinguishing (Off).
6.LAMP
Off
Off
▲
Off
