Table of Contents
Safety Precautions and Warnings ...................................... 2
Table of Contents .............................................................. 3
Box Contents .................................................................... 3
First Flight Preparation ...................................................... 4
Flying Checklist ................................................................ 4
Charging Warnings............................................................ 4
Battery Charging ............................................................... 4
Installing the DXe Transmitter Batteries (RTF) .................... 5
DXe Transmitter Control (RTF) ........................................... 5
Transmitter Setup Table (BNF) ........................................... 6
Installing the Flight Battery ............................................... 8
Transmitter and Receiver Binding ...................................... 8
®
SAFE Technology ............................................................ 9
Flight Mode and Rate Selection ......................................... 9
Panic Recovery ................................................................. 9
Throttle Hold ................................................................... 10
Airframe
Main Motor
Tail Motor
Receiver
ESC
Battery
Charger
Transmitter
Length
Height
Main Rotor Diameter
Box Contents
• Blade ® AH-64 Apache ™
™
• Spektrum DXe Transmitter (RTF Only)
• 400mAh 2S 7.4V 30 C Li-Po Battery
Components
Blade ® AH-64 Apache ™
6000kv Brushless Outrunner
4800k Brushless Outrunner
Spektrum AR6335
Dual Brushless
400mAh 2S 7.4V 30 C Li-Po Battery
2-3 Cell LiPo Balancing Charger, 0.65A
® ®
DSM2 /DSMX Compatible Transmitter
Specifications
14.76 in (375mm)
3.74 in (95mm)
12.51 in (318mm)
Control Tests ................................................................... 10
Understanding the Primary Flight Controls ...................... 11
Flying the AH-64 Apache Helicopter ................................ 12
Advanced Settings .......................................................... 12
Servo Adjustment ........................................................... 14
Trim Flight ...................................................................... 15
Post-Flight Inspection and Maintenance Checklist ........... 16
Troubleshooting Guide .................................................... 16
Exploded View ................................................................ 18
Parts Listings .................................................................. 18
Optional Parts ................................................................. 18
Limited Warranty ............................................................ 19
Warranty and Service Contact Information ...................... 20
FCC Information .............................................................. 20
IC Information ................................................................. 20
Compliance Information for the European Union .............. 21
DXe Included
Tail Rotor Diameter
Flying Weight
To register your product online,visit www.bladehelis.com
• E-fl ite ® 2-3 Cell LiPo Balancing Charger, 0.65A with AC
to 12VDC Power Supply
• 4 AA Batteries (RTF Only)
3
RTF BNF
Included Included
Installed Installed
Installed Installed
Installed Installed
Installed Installed
Included Included
Included Included
Required
2.56 in (65mm)
6.70 oz (190 g)
EN
